General
0.37 kg (0.82 lb)
Installation Mode
Desk-Mounted,Wall-Mounted,Ceiling Mounting
Working Temperature
0 °C to 40 °C (32 °F to 104 °F)
Working Humidity
5% to 95% (no condensation)
Storage Temperature
-40 °C to 70 °C (-40 °F to 158 °F)
Storage Humidity
5% to 95% (no condensation)
Product Dimensions (W × H × D)
220 mm × 220 mm × 39 mm (8.66'' × 8.66'' × 1.54'')
Packing List
1800 M Access Point ×1,Screw Pack × 1,Quick Start Guide ×1,Regulatory Compliance and Safety Information × 1
Power Consumption
Max. 11.35 W
Hardware Specifications
Interface
1 × Gigabit RJ45 uplink port
Power Supply
IEEE 802.3af/at POE,12 VDC 1.5 A
LED Indicator
Yellow/green/blue for different working states, flashing mode
Reset Button
Hardware Resetting Button
WLAN Parameters
Maximum Number of Clients
256
Recommended Number of Clients
100
Maximum Number of SSIDs
8
Working Frequency Band
radio 1: 5G(11a/n/ac/ax), radio 2: 2.4G(11b/g/n/ax)
Wi-Fi Standards
Wi-Fi 6
Wi-Fi Speed
2.4 G: 574 Mbps,5 G: 1201 Mbps
Spatial Streams
2.4 GHz, 2 × 2 , MU-MIMO, 5 GHz, 2 ×2 , MU-MIMO
Channel Width
2.4 GHz: Auto/20 /40 MHz,5 GHz: Auto/20 /40 /80/MHz
Number of Antennas
2.4GHz:2;5GHz:2
Antenna Type
Built-in omnidirectional antennas
Antenna Gain
2.4 GHz: 3 dBi,5 GHz: 4 dBi
Transmit Power
20 dBm
Modulation Technology
OFDM:BPSK@6/9Mbps?QPSK@12/18Mbps?16-QAM@24Mbps?64-QAM@48/54Mbps; DSSS: DBPSK@1Mbps?DQPSK@2Mbps?CCK@5.5/11Mbps; MIMO-OFDM(11n):MCS 0-15; MIMO-OFDM(11ac): MCS 0-9; MIMO-OFDM(11ax): MCS 0-11
Software Specifications
WLAN Security
WAP-PSK,WAP2-PSK,WPA-WAP2-PSK,Blocklist & Allowlist,Support Multiple encryption key triggered dynamic unicast/multicast key update,Support Open system/shared key authentication,Support wireless endpoint access,Support SSID and VLAN binding,Support 802.11i
Management & Maintenance
Centralized AC management
Version Upgrade
upgrade on Web
Approval
EMC
CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020)
Safety
CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017),UL (UL 60950-1)
Chemistry
CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006)
Radio
EN 301 893,EN 300 440,EN 62311,EN 301 489-3,EN 301 489-17
